FORD DA8Z9A299B, DB5Z9H307B, DB5Z9H307C, DA8Z9H307J, DB5Z9A407A Electric Fuel Pump Assembly

Description: Fuel Pump Module Assembly
Gaskets Included: Yes
Height (in): 9.8
Max Pressure Range (Psi): 64
Max Free Flow (Gph): 71
Resistance Empty (Ohms): 180
Resistance Full (Ohms): 10
Rheostat Range (Ohms): 180-10
Outlet Quantity: 1
Outlet Type: Quick Connect
Outlet Diameter (IN): 3/8
Compatible Fuels: Gas
Wiring Harness Included: No
Hardware Included: Yes
Min Free Flow Rate (Gph): 62
Min Pressure Range (Psi): 58
Strainer Included: Yes
Pin Count: 4
Pin Shape: Flat
Connector Shape: Trapeze
Connector Gender: Male
Inline Pump: No
In Tank: Yes
Negative Ground: Yes
Pump Type: Turbine
Volts: 12 vDC

FORD DA8Z9A299B, DB5Z9H307B, DB5Z 9H307 B, DB5Z9H307C, DB5Z 9H307 C, DA8Z9H307J, DA8Z 9H307 J, DB5Z9A407A,

SPECTRA PREMIUM SP2520M
DELPHI FG1551
AIRTEX E2605M
MOTORCRAFT PS611, PFS998
CARTER P76859M

FORD EXPLORER 2013-2018
FORD POLICE INTERCEPTOR UTILITY 2013-2016
