Camshaft Position Sensor

Vehicles can’t run without ignition and fuel injection. These are complicated
operation, and some sensors get involved. The camshaft position sensor
is the one. If you want excellent wholesale products, welcome to Delcoribo.

Delcoribo Camshaft Position Sensors

You Need Good Camshaft Position Sensor for Fuel Injection And Ignition

Accurate Measurement Even in Extreme Temperatures. Ideal Fuel Mileage And Less CO₂ in Emissions.
Advanced Circuitry to Prevent Electrical Interference. Not Afraid of Overloaded Voltages And Currents.

Updated: August 12, 2022

1. Introduction

During starting, it is not possible to distinguish between these two kinds from the crankshaft position signal alone. At this point, the camshaft position sensor plays a role in accurately determining the position of the compression top dead center. As a result, the ignition timing will change.

In contrast, the signal generated by the crankshaft speed sensor is sufficient to determine the state of the diesel engine when the vehicle is running. This means that if the camshaft position sensor fails during vehicle running, the ECU is still able to determine the state of the diesel engine.

A shaft is generally equipped with a number of cams, which are mechanically linked to the equipment being tested. It moves in a fixed position around the circumference as the equipment rotates. The cams will be topped with mechanical contacts at the desired position so that they can be opened or closed to give a signal to control the equipment.

The camshaft position sensor uses the Hall effect to determine the position of the camshaft: a tooth made of ferromagnetic material is placed on the camshaft, which rotates with the camshaft.

When the tooth passes the Hall-effect semiconductor sheet in the camshaft position sensor through which the current flows, the magnetic field of the sensor deflects the flow of electrons in the Hall-effect semiconductor sheet perpendicular to the direction of the current, thus creating a voltage signal for a short period of time, which informs the ECU that the first cylinder is precisely at the top dead center of the compression stroke.

When the camshaft position sensor has a problem (such as unplugging the harness), you can't tell whether the diesel engine can start successfully. It should be considered depending on the specific car model. Even if the same electronic fuel injection system is used, some models can start while others cannot, depending on the control strategy of the system.

2. Symptoms

Common issues of camshaft position sensor are mainly increased fuel consumption, weak acceleration, bad ignition, difficult starting, unstable idling, fault light on, poor power, occasional stuttering while driving, and accelerated engine abrasion.

The engine is hard to start, or it even can't start; that is, it does not ignite. This is because the camshaft position sensor can predict the ignition sequence. If there is a malfunction, it will naturally have a difficult start.

The fuel consumption increases in the engine. If the camshaft position sensor is faulty, the car computer will not be able to inject fuel accurately, causing an increase in fuel consumption.

The engine ping happens, and the check engine light stays on.

3. Test

Here is the method of the camshaft position sensor test. The camshaft position sensor is a three-wire Hall sensor. Prepare a 12-volt or 5-volt power line, a signal line, and a lap wire. Turn the key to ignite the engine, and use a voltmeter to measure and determine the voltage output of the power line.

Use the table to determine the lap wire, and connect a meter stick to the determined power line. Connect another meter stick to the other two wires to measure. The remaining one is the signal line. Turn off the key to draw out the signal line, plug it back in and start the engine.

Measure the signal line and the latch line to see if there is a signal voltage output. The voltage should be less than the supply voltage, and there is no damage to the sensor. The camshaft position sensor also detects the rotation angle.

4. Reasons for Choosing Delcoribo Camshaft Position Sensors

That’s annoying when the car can’t start before going to work. A defective camshaft position sensor could be the culprit. Engines need exact information of camshaft position to perform well in all conditions. There must be some durable sensors to transmit signals without mistakes.

Delcoribo produces superior camshaft position sensors with long service life. Our products endure large range of operation temperatures and report data without compromise. The accurate measurement helps to get proper fuel injection. Vehicles can get optimum fuel economy after replacement.

Static electricity can cause damage to auto parts. Delcoribo implements advanced technology to protect our components from electrical interference. In spite of working in sophisticated situations, our camshaft position sensors always maintain good performance and work well with other parts.
