FORD 8A4Z9H307C, 8A4Z-9H307-C, 8A4Z9H307A, 8A4Z-9H307A Electric Fuel Pump Assembly

FORD 8A4Z9H307C, 8A4Z-9H307-C, 8A4Z9H307A, 8A4Z-9H307A Electric Fuel Pump Assembly

FORD 8A4Z9H307C, 8A4Z-9H307-C, 8A4Z9H307A, 8A4Z-9H307A Electric Fuel Pump Assembly
FPM1169 FORD Electric Fuel Pump Assembly
Description: Fuel Pump Module Assembly
Gaskets Included: No
Height (in): 10.2
Max Pressure Range (Psi): 65.7
Max Free Flow (Gph): 61.3
Resistance Empty (Ohms): 180
Resistance Full (Ohms): 10
Rheostat Range (Ohms): 180-10
Outlet Quantity: 1
Outlet Type: Quick Connect
Outlet Diameter (IN): 3/8
Compatible Fuels: Gas
Wiring Harness Included: Yes
Hardware Included: Yes
Min Free Flow Rate (Gph): 52.0
Min Pressure Range (Psi): 65.7
Strainer Included: Yes
Pin Count: 4
Pin Shape: Flat
Connector Shape: Trapeze
Connector Gender: Male
Inline Pump: No
In Tank: Yes
Negative Ground: Yes
Volts: 12 vDC
FORD 8A4Z9H307C, 8A4Z 9H307 C, 8A4Z9H307A, 8A4Z 9H307 A,
SPECTRA PREMIUM SP2498M
DELPHI FG2058
AIRTEX E2507M
CARTER P76454M
MOTORCRAFT PFS528
FORD TAURUS X 2008-2009
