HYUNDAI 311103M000, 31110-3M000, 311103M100, 31110-3M100, 311103M900, 31110-3M900 Electric Fuel Pump Assembly

HYUNDAI 311103M000, 31110-3M000, 311103M100, 31110-3M100, 311103M900, 31110-3M900 Electric Fuel Pump Assembly

HYUNDAI 311103M000, 31110-3M000, 311103M100, 31110-3M100, 311103M900, 31110-3M900 Electric Fuel Pump Assembly
FPM1262 HYUNDAI Electric Fuel Pump Assembly
Description: Fuel Pump Module Assembly
Gaskets Included: Yes
Height (in): 9.4
Max Pressure Range (Psi): 95
Max Free Flow (Gph): 55
Resistance Empty (Ohms): 95
Resistance Full (Ohms): 3
Rheostat Range (Ohms): 95-3
Outlet Quantity: 1
Outlet Type: Quick Connect
Outlet Diameter (IN): 5/16
Compatible Fuels: Gas
Wiring Harness Included: No
Hardware Included: Yes
Min Free Flow Rate (Gph): 45
Min Pressure Range (Psi): 85
Strainer Included: Yes
Pin Count: 4
Pin Shape: Flat
Connector Shape: Trapeze
Connector Gender: Male
Inline Pump: No
In Tank: Yes
Negative Ground: Yes
Pump Type: Turbine
Volts: 12 vDC
HYUNDAI 311103M000, 311103M100, 311103M900,
SPECTRA PREMIUM SP3073M
AIRTEX E9124M
HYUNDAI GENESIS 2009-2014
