JAGUAR C2S17863, C2S20036, C2S21293, C2S24056 Electric Fuel Pump Assembly

JAGUAR C2S17863, C2S20036, C2S21293, C2S24056 Electric Fuel Pump Assembly

JAGUAR C2S17863, C2S20036, C2S21293, C2S24056 Electric Fuel Pump Assembly
FPM1510 JAGUAR Electric Fuel Pump Assembly
Description: Fuel Pump Module Assembly
Gaskets Included: Yes
Height (in): 10.1
Max Pressure Range (Psi): 130
Max Free Flow (Gph): 65
Resistance Empty (Ohms): 15
Resistance Full (Ohms): 160
Rheostat Range (Ohms): 15-160
Outlet Quantity: 1
Outlet Type: Quick Connect
Outlet Diameter (IN): 25/64
Compatible Fuels: Gas
Wiring Harness Included: No
Hardware Included: Yes
Min Free Flow Rate (Gph): 55
Min Pressure Range (Psi): 90
Strainer Included: Yes
Pin Count: 4
Pin Shape: Round
Connector Shape: Round
Connector Gender: Male
Inline Pump: No
In Tank: Yes
Negative Ground: Yes
Pump Type: Turbine
Volts: 12 vDC
JAGUAR C2S17863, C2S20036, C2S21293, C2S24056, C2S26265, C2S29910, C2S33404, C2S35274,
SPECTRA PREMIUM SP5064M
DELPHI FG1655
AIRTEX E8576M
JAGUAR X-TYPE 2002-2003
