Fuel System
>
Electric Fuel Pump Assembly
>
BUICK 19177222, 19180110, 19331277, 19331287, 25320815, 25326814, 25344968, 25349607, 89060194 Electric Fuel Pump Assembly

BUICK 19177222, 19180110, 19331277, 19331287, 25320815, 25326814, 25344968, 25349607, 89060194 Electric Fuel Pump Assembly

BUICK 19177222, 19180110, 19331277, 19331287, 25320815, 25326814, 25344968, 25349607, 89060194 Electric Fuel Pump Assembly
FPM1690 BUICK Electric Fuel Pump Assembly
Description: Fuel Pump Module Assembly
Gaskets Included: Yes
Height (in): 12.05
Max Pressure Range (Psi): 123.25
Max Free Flow (Gph): 56.94
Resistance Empty (Ohms): 39
Resistance Full (Ohms): 250
Rheostat Range (Ohms): 39-250
Inlet Quantity: 1
Inlet Type: Quick Connect
Inlet Diameter (IN): 5/16
Outlet Quantity: 1
Outlet Type: Quick Connect
Outlet Diameter (IN): 3/8
Compatible Fuels: Gas
Wiring Harness Included: Yes
Hardware Included: Yes
Min Free Flow Rate (Gph): 47.65
Min Pressure Range (Psi): 79.75
Strainer Included: Yes
Pin Count: 4
Pin Shape: Flat
Connector Shape: Oval
Connector Gender: Male
Inline Pump: No
In Tank: Yes
Negative Ground: Yes
Pump Type: Turbine
Volts: 12 vDC
19177222, 19180110, 19331277, 19331287, 25320815, 25326814, 25344968, 25349607, 89060194, P1004M, P1026M,
SPECTRA PREMIUM SP6005M
DELPHI FG0260
DELPHI FG0343
AIRTEX E3519M
AIRTEX E3601M
ACDELCO MU1741
BRUTE POWER 1010258
CARTER P74984M
BUICK REGAL 2000-2004
PONTIAC GRAND PRIX 2001-2003
