FORD HC3Z9H307K, HC3Z-9H307-K, HC3Z9H307V, HC3Z-9H307-V Electric Fuel Pump Assembly

System Pressure 52 psi
Package Contents Fuel Pump Module Assembly w/Float Arm, Instruction Sheet
Fuel Level Sender Assembly Included Yes
Vapor Pressure Sensor Yes
Outlet Outside Diameter (in) 0.375
Voltage (2H) 12.0
Fuel Type Gas
Regulator Included Yes
Maximum Pressure (PS) 58.0
Terminal Type Blade
Gasket or Seal Included No
Terminal Quantity 4
Lock Ring Included No
Terminal Gender Male
Strainer Included Yes
Inlet Type Strainer
Outlet Type Quick Connect
Outlet Quantity 1
In Tank or External In Tank
Resistance Ohms Empty 180.0
Resistance Ohms Full 10.0
Internal Or External Strainer Internal
Average Current Draw (A) 10
Average Flow Rating (GP) 48
Pump Type Electric

HC3Z9H307K, HC3Z9H307V, HC3Z 9H307 V, PFS1232,

DELPHI FG2321

FORD F-250 SUPER DUTY 2017-2019
FORD F-350 SUPER DUTY 2017-2019
