DELPHI FG2087, AUDI 8R0919051E, 8R0-919-051-E Electric Fuel Pump Assembly

Fuel Type Flex
Package Contents Fuel Pump Module Assembly w/Float Arm, Instruction Sheet
System Pressure 51 psi
Vapor Pressure Sensor No
Fuel Level Sender Assembly Included Yes
Outlet Outside Diameter (in) 0.313
Voltage (2H) 12.0
Regulator Included Yes
Terminal Type Blade
Gasket or Seal Included No
Terminal Quantity 4
Lock Ring Included No
Terminal Gender Male
Strainer Included Yes
Inlet Type Strainer
Outlet Type Quick Connect
Outlet Quantity 1
In Tank or External In Tank
Resistance Ohms Empty 62.0
Resistance Ohms Full 290.0
Internal Or External Strainer Internal
Average Current Draw (A) 10
Pump Type Electric

8R0919051E,

DELPHI FG2087

AUDI Q5 2013-2017
AUDI SQ5 2014-2017
