FORD BV6Z9H307AW, BV6Z-9H307-AW, BV6Z9H307M, BV6Z9H307R, BV6Z-9H307-R, BV6Z9H307V Electric Fuel Pump Assembly

Description Fuel Pump Module Assembly
Gaskets Included No
Height (in) 9.5
Max Pressure Range (Psi) 120
Max Free Flow (Gph) 65
Resistance Empty (Ohms) 465
Resistance Full (Ohms) 50
Rheostat Range (Ohms) 465-50
Outlet Quantity 1
Outlet Type Quick Connect
Outlet Diameter (IN) 5/16
Compatible Fuels Gas
Wiring Harness Included No
Hardware Included Yes
Min Free Flow Rate (Gph) 55
Min Pressure Range (Psi) 110
Strainer Included Yes
Pin Count 4
Pin Shape Flat
Connector Shape Trapeze
Connector Gender Male
Inline Pump No
In Tank Yes
Negative Ground Yes
Pump Type Turbine
Volts 12 vDC

BV6Z9H307AW, BV6Z9H307M, BV6Z 9H307 M, BV6Z9H307R, BV6Z 9H307 R, BV6Z9H307V, BV6Z 9H307 V,

SPECTRA PREMIUM SP2543M
DELPHI FG1937
BOSCH 66094
BOSCH F 00E 194 654 F00E194654

FORD FOCUS 2013-2018
