FORD XL3Z9H307AB, XL3Z9H307BA, XL3Z9H307BB, XL3Z9H307DB, XL3Z9H307EB, XL3Z9H307FB, F75Z9H307AD Electric Fuel Pump Assembly

Description: Fuel Pump And Sender Assembly
Gaskets Included: Yes
Height (in): 12.9
Max Pressure Range (Psi): 123
Max Free Flow (Gph): 59
Resistance Empty (Ohms): 15
Resistance Full (Ohms): 160
Rheostat Range (Ohms): 15-160
Inlet Quantity: 1
Inlet Type: Quick Connect
Inlet Diameter (IN): 5/16
Outlet Quantity: 1
Outlet Type: Quick Connect
Outlet Diameter (IN): 3/8
Compatible Fuels: Gas
Wiring Harness Included: No
Hardware Included: Yes
Min Free Flow Rate (Gph): 50
Min Pressure Range (Psi): 80
Strainer Included: Yes
Pin Count: 4
Pin Shape: Round
Connector Shape: Round
Connector Gender: Male
Inline Pump: No
In Tank: Yes
Negative Ground: Yes
Pump Type: Turbine
Volts: 12 vDC

FORD P2528S, P2616S, P2617S, XL3Z9H307AB, XL3Z 9H307 AB, XL3Z9H307BA, XL3Z 9H307 BA, XL3Z9H307BB, XL3Z 9H307 BB, XL3Z9H307DB, XL3Z 9H307 DB, XL3Z9H307EB, XL3Z 9H307 EB, XL3Z9H307FB, XL3Z 9H307 FB, F75Z9H307AD, F75Z 9H307 AD, XL3U9H307CB, XL3U 9H307 CB, XL3U9H307FB, XL3U 9H307 FB, XL3Z9H307CB, XL3Z 9H307 CB, XL3Z9H307AA, XL3Z 9H307 AA, XL3Z9H307DA, XL3Z 9H307 DA, XL3Z9H307EA, XL3Z 9H307 EA, XL3Z9H307CA, XL3Z 9H307 CA, XL3Z9H307FA, XL3Z 9H307 FA,

SPECTRA PREMIUM SP2237H, SP2229H
BOSCH 67232
BOSCH 66118
DELPHI HP10071
DELPHI HP10089
AIRTEX E2237S
AIRTEX E2229S
