FORD E7TZ9H307A, E7TZ9H307AA, P222H, E9TF9H307JA Electric Fuel Pump Assembly

Description Fuel Pump And Sender Assembly
Gaskets Included Yes
Height (in) 10.2
Max Pressure Range (Psi) 8.5
Max Free Flow (Gph) 42.3
Resistance Empty (Ohms) 10
Resistance Full (Ohms) 165
Rheostat Range (Ohms) 10-165
Inlet Quantity 1
Inlet Type Quick Connect
Inlet Diameter (IN) 5/16
Outlet Quantity 1
Outlet Type Quick Connect
Outlet Diameter (IN) 3/8
Compatible Fuels Gas
Wiring Harness Included No
Hardware Included Yes
Min Free Flow Rate (Gph) 31.7
Min Pressure Range (Psi) 5
Strainer Included Yes
Pin Count 4
Pin Shape Round
Connector Shape Oval
Connector Gender Male
Inline Pump No
In Tank Yes
Negative Ground Yes
Pump Type Turbine
Volts 12 vDC

FORD E7TZ9H307A, E7TZ 9H307 A, E7TZ9H307AA, E7TZ 9H307 AA, P222H, E9TF9H307JA, E9TF 9H307 JA,

SPECTRA PREMIUM SP222H, FG34A
DELPHI HP10170
AIRTEX E2102S
CARTER P74517S
DORMAN 692064
