FORD E8TZ9H307E, E8TZ-9H307-E, E8TZ9H307EA, E8TZ-9H307-EA, E5TZ9H307H Electric Fuel Pump Assembly

FORD E8TZ9H307E, E8TZ-9H307-E, E8TZ9H307EA, E8TZ-9H307-EA, E5TZ9H307H Electric Fuel Pump Assembly

FORD E8TZ9H307E, E8TZ-9H307-E, E8TZ9H307EA, E8TZ-9H307-EA, E5TZ9H307H Electric Fuel Pump Assembly
FPM2741  Electric Fuel Pump Assembly
Description Fuel Pump And Sender Assembly
Gaskets Included Yes
Height (in) 15.0
Max Pressure Range (Psi) 8.7
Max Free Flow (Gph) 42.3
Resistance Empty (Ohms) 70
Resistance Full (Ohms) 10
Rheostat Range (Ohms) 70-10
Inlet Quantity 1
Inlet Type Quick Connect
Inlet Diameter (IN) 5/16
Outlet Quantity 1
Outlet Type Quick Connect
Outlet Diameter (IN) 3/8
Compatible Fuels Gas
Wiring Harness Included No
Hardware Included Yes
Min Free Flow Rate (Gph) 2.2
Min Pressure Range (Psi) 4.4
Strainer Included Yes
Pin Count 4
Pin Shape Round
Connector Shape Oval
Connector Gender Male
Inline Pump No
In Tank Yes
Negative Ground Yes
Pump Type Peripheral
Volts 12 vDC
FORD E8TZ9H307E, E8TZ 9H307 E, E8TZ9H307EA, E8TZ 9H307 EA, P378H, E5TZ9H307H, E5TZ 9H307 H,
SPECTRA PREMIUM SP378H
DELPHI HP10167
AIRTEX E2097S
DORMAN 692113
