Fuel System
>
Electric Fuel Pump Assembly
>
TOYOTA 232200C010, 23220-0C010, 7720304070, 77203-04070, 8332035560, 83320-35560 Electric Fuel Pump Assembly

TOYOTA 232200C010, 23220-0C010, 7720304070, 77203-04070, 8332035560, 83320-35560 Electric Fuel Pump Assembly

TOYOTA 232200C010, 23220-0C010, 7720304070, 77203-04070, 8332035560, 83320-35560 Electric Fuel Pump Assembly
FPM2781  Electric Fuel Pump Assembly
Description: Fuel Pump And Sender Assembly
Gaskets Included: Yes
Height (in): 12.7
Max Pressure Range (Psi): 108.8
Max Free Flow (Gph): 54.2
Resistance Empty (Ohms): 110
Resistance Full (Ohms): 3
Rheostat Range (Ohms): 110-3
Inlet Quantity: 1
Inlet Type: Butt Flare
Inlet Diameter (IN): 1/4
Outlet Quantity: 1
Outlet Type: Quick Connect
Outlet Diameter (IN): 5/16
Compatible Fuels: Gas
Wiring Harness Included: No
Hardware Included: Yes
Min Free Flow Rate (Gph): 44.9
Min Pressure Range (Psi): 79.8
Strainer Included: Yes
Pin Count: 5
Pin Shape: Flat
Connector Shape: Trapeze
Connector Gender: Male
Inline Pump: No
In Tank: Yes
Negative Ground: Yes
Pump Type: Turbine
Volts: 12 vDC
232200C010, 7720304070, 8332035560,
SPECTRA PREMIUM SP9004H
DELPHI HP10254
