Ford Alternator Rectifiers F8AU-10A366-AAIP, F8AU10A366AA, PowerMax 81110190

Diodes: 8-50 Ampere

230870, FR6023, (Ref# 31-212-1), Rectifier, For: Ford 6G Series 130-135A* IR/IF, Alternators, Used On: (2005-98) Ford, Lincoln, Mercury, Replaces: Ford F8AU-10A366-AAIP, F8AU10A366AA, Unit Nos: Ford 3W1U-10300-BB, 3W1Z-10346-BA, F8AU-10300-AB, F8AU-10300-AC, F8AU-10300-AD, F8AZ-10346-AB, F8ZU-10300-AC, XF2U-10300-BC, XF2U-10300-BD, XF2Z-10346-BA, 6G SERIES 135 A, 3W1U10300BB, 3W1Z10346BA, F8AU10300AB, F8AU10300AC, F8AU10300AD, F8AZ10346AB, F8ZU10300AC, XF2U10300BC, XF2U10300BD, XF2Z10346BA, 6GSERIES135A Lester Nos: 7795, 8253, 8315, Dim: 149mm Heat Sink OD, Note: *FR6023 is the early design, 8-diode rectifier for 6G stators with, 2-leads/phase and Y-connection., Features: 50A/300V press-fit diodes, OE validated Crimp-weld diode terminations Heavy duty copper connections reduce, high-amp heat generation Pre-tinned terminals improves, solder-ability Drop-down stator connection improves, salvage rate for short-lead stators

MOBILETRON RF-123 RF123, RF-123HV RF123HV
PowerMax 81110190
AS-PL ARC9015
ERA 215212
MESSMER 215212
WAIglobal FR6023, FR6023SP, FR6023SPM8

FORD USA WINDSTAR (A3) 1995/01 - /
1998-2003 FORD , Lincoln , Mercury
