Valeo 545940, NF007, A546860A, 592937, 592847, 592846, 2545941, for RENAULT Alternator Rectifiers

Diodes: 8-35 Amp
Diameter OD: 107mm

135518, IPR846, Rectifier, For: Paris Rhone/Valeo 75-110A IR/IF, Alternators, Used On: Renault, Peugeot, Replaces: Valeo 545940, NF007, A546860A, 592937, 592847, 592846, 2545941, UBB252, MOBILETRON RP-17, MAGNETI MARELLI 940038316, Unit Nos: Paris Rhone/Valeo 11VI29, 11VI30, 11VI31, 11VI59, 11VI61, A13VI11, A13VI13, A13VI14, A13VI16, A13VI17, A13VI20, A13VI21, A13VI22, A13VI23, A13VI25, A13VI28, A13VI30, A13VI32, A13VI34, A13VI35, A13VI45, A13VI47, A13VI52, A13VI55, A13VI57, A13VI62, A13VI64, A13VI65, A13VI66, A13V104, A13V105, A13V106, A13V107, A13V131, A13V153, Valeo 2541244, 2541262, 2541307, 2541307C, 2541307D, 2541308, 2541310, 2541311, 2541325, 2541339, 2541339E, 2541339I, 2541340, 2541344, 2541343, 2541349, 2541359, 2541386, 2541393, 2541394, 2541443, 2541448, 2541485, 2541600, 2541602, 2541603, 2541604, 2541608, 2541610, 2541610B, 2541613, 2541625, 2541641, 2541642, 2541643, 2541788, 2541789, 2541790, 2541791, 2541797, 2541826, WAI Ref. Nos: 1-2278-01VA, 1227801VA, Dim: 107mm OD, M6 x 1.0 x 19mm, M8 x 1.25 x 19mm, Stepped Batt. Term., Note: With W-terminal., Similar to IPR847 except: , IPR846: 8-diode rectifier, IPR847: 6-diode rectifier, Features: 8-35A press-fit avalanche diodes

AS-PL ARC3012, ARC3013
CASCO CRC15104AS
ERA 215761
LAUBER CQ1080375
MESSMER 215761
PowerMax 1111800, 81111800
SANDO SRC15104.0 SRC151040
WAIglobal IPR846

RENAULT RAPID Box (F40_, G40_) 1985/07 - 1998/11
RENAULT CLIO I (B/C57_, 5/357_) 1990/05 - 1998/09
RENAULT LAGUNA I (B56_, 556_) 1993/11 - 2001/03
RENAULT 19 I Chamade (L53_) 1988/01 - 1992/12
RENAULT 19 II (B/C53_) 1991/01 - 2001/06
RENAULT 19 II Chamade (L53_) 1992/04 - 2003/08
RENAULT MEGANE Scenic (JA0/1_) 1996/10 - 2001/12
RENAULT 19 II Box (S53_) 1992/03 - 1995/12
