HONDA Voltage Regulator 126000-1470, 126000-1471, 1260001470

A-Circuit
Voitage Set Point 14.5V
63.5mm Mounting

IN429
(Ref# 35-8231-1)
Regulator
12 Volt, A-Circuit, D-FR-IG-L Terminals, 14.5 Vset, w/ LRC
For: Nippondenso IR/IF Alternators
Used On: (1993-92) Acura
Replaces: Nippondenso 126000-1470, 126000-1471, 1260001470, 1260001471 MOBILETRON VR-H2005-19A, VRH200519A
Unit Nos: Honda 31100-PR4-C01, 31100PR4C01 Nippondenso 100211-891, 100211-910, 100211891, 100211910
Lester Nos: 13433
WAI Ref. Nos: 1-1963-01ND
Dim: 63.5mm Mtg. Length
Note: L-terminal is an output terminal.
Similar to IN225 except IN225 wo/ LRC feature.

ALANKO 700439
AS-PL ARE6023
CASCO CRE40125AS
LAUBER CQ1010457
MAGNETI MARELLI 940016084200
PowerMax 1110703, 81110703
SANDO SRE40125.0 SRE401250
WAIglobal IN429
MOBILETRON VR-H2005-19A VRH200519A

HONDA CIVIC IV Hatchback (EC, ED, EE) 1987/09 - 1993/10
HONDA CRX I (AF, AS) 1983/10 - 1987/10
HONDA CIVIC V Hatchback (EG) 1991/10 - 1995/11
HONDA CIVIC VI Coupe (EJ, EM1) 1996/03 - 2000/12
TOYOTA COROLLA Compact (_E9_) 1987/05 - 1995/10
TOYOTA COROLLA Coupe (AE86) 1983/05 - 1987/07
TOYOTA MR 2 I (AW1_) 1984/06 - 1990/06
TOYOTA CAMRY Saloon (_V1_) 1983/02 - 1988/07
TOYOTA CAMRY (_V2_) 1986/10 - 1993/02
TOYOTA CAMRY Liftback (_V1_) 1983/01 - 1988/01
TOYOTA CARINA II Saloon (_T15_) 1983/08 - 1988/05
TOYOTA CARINA II (_T15_) 1983/10 - 1988/05
TOYOTA CELICA Hatchback (ST16_, AT16_) 1985/08 - 1989/12
TOYOTA COROLLA FX Compact (E8B) 1984/08 - 1988/05
TOYOTA CELICA (AT16_, ST16_) 1985/08 - 1989/08
