Motorola Prestolite 8RH2004D, 8RH2004E Voltage Regulator
VRT1707 Voltage Regulators
M5-146
Regulator
12 Volt, B-Circuit, 15.2 Vset
For: Motorola / Prestolite 8AL, A12N Series Alternators
Replaces: Motorola / Prestolite 8RH2004D, 8RH2004E, 105-139, 105-146
Unit Nos: Motorola / Prestolite 8AL2004F, 2005F, 2006F, 2007F, 2008K, 2009K, 2020L, A12NAM456, A12NAM457, A12NAM606, A12NAM607, A12NJD454, 110-30, 110-101, 110-102, 110-118, 110-119, 110-120, 11030, 110101, 110102, 110118, 110119, 110120
Lester Nos: 7353, 7391, 7395
Terminal ID: Plug-Type N;Wiring Code 3
Red Isolation Diode (+), Black Ground, Green Field, Yellow Ignition.
Note: For adjustable voltage use M5-146A.
Regulator
12 Volt, B-Circuit, 15.2 Vset
For: Motorola / Prestolite 8AL, A12N Series Alternators
Replaces: Motorola / Prestolite 8RH2004D, 8RH2004E, 105-139, 105-146
Unit Nos: Motorola / Prestolite 8AL2004F, 2005F, 2006F, 2007F, 2008K, 2009K, 2020L, A12NAM456, A12NAM457, A12NAM606, A12NAM607, A12NJD454, 110-30, 110-101, 110-102, 110-118, 110-119, 110-120, 11030, 110101, 110102, 110118, 110119, 110120
Lester Nos: 7353, 7391, 7395
Terminal ID: Plug-Type N;Wiring Code 3
Red Isolation Diode (+), Black Ground, Green Field, Yellow Ignition.
Note: For adjustable voltage use M5-146A.
WAIglobal M5-146 M5146, M5-146A M5146A
