Fuel System
>
Electric Fuel Pump Assembly
>
AIRTEX E9085M, SUBARU 42021SC030, 42022SG010, 42022-SG010 Electric Fuel Pump Assembly

AIRTEX E9085M, SUBARU 42021SC030, 42022SG010, 42022-SG010 Electric Fuel Pump Assembly

AIRTEX E9085M, SUBARU 42021SC030, 42022SG010, 42022-SG010 Electric Fuel Pump Assembly
FPM2119 SUBARU Electric Fuel Pump Assembly
Description Fuel Pump Module Assembly
Gaskets Included Yes
Height (in) 8.6
Max Pressure Range (Psi) 58
Max Free Flow (Gph) 74
Resistance Empty (Ohms) 33
Resistance Full (Ohms) 2
Rheostat Range (Ohms) 32.5-2.1
Inlet Quantity 1
Inlet Type Quick Connect
Inlet Diameter (IN) 3/8
Outlet Quantity 1
Outlet Type Quick Connect
Outlet Diameter (IN) 3/8
Compatible Fuels Gas
Wiring Harness Included No
Hardware Included Yes
Min Free Flow Rate (Gph) 49
Min Pressure Range (Psi) 52
Strainer Included Yes
Pin Count 6
Pin Shape Flat
Connector Shape Rectangular
Connector Gender Male
Inline Pump No
In Tank Yes
Negative Ground Yes
Pump Type Turbine
Volts 12 vDC
42021SC030, 42022SG010,
SPECTRA PREMIUM SP4101M
AIRTEX E9085M
DELPHI FG1552
HITACHI FUP0037
SUBARU FORESTER 2011-2013
