GM 19111386, 25027221, 25094812 Electric Fuel Pump Assembly

GM 19111386, 25027221, 25094812 Electric Fuel Pump Assembly

GM 19111386, 25027221, 25094812 Electric Fuel Pump Assembly
FPM2650  Electric Fuel Pump Assembly
Description: Fuel Pump And Sender Assembly
Gaskets Included: Yes
Height (in): 11.4
Max Pressure Range (Psi): 101.5
Max Free Flow (Gph): 52.5
Resistance Empty (Ohms): 0
Resistance Full (Ohms): 95
Rheostat Range (Ohms): 0-95
Inlet Quantity: 1
Inlet Type: Butt Flare
Inlet Diameter (IN): 5/16
Outlet Quantity: 1
Outlet Type: Inverted Flare
Outlet Thread Sizes: M16-1.5
Compatible Fuels: Gas
Wiring Harness Included: No
Hardware Included: Yes
Min Free Flow Rate (Gph): 46.3
Min Pressure Range (Psi): 94
Strainer Included: Yes
Pin Count: 3
Pin Shape: Round
Connector Shape: Oval
Connector Gender: Female
Inline Pump: No
In Tank: Yes
Negative Ground: Yes
Pump Type: Turbine
Volts: 12 vDC
GM 19111386, 25027221, 25094812,
ACDELCO FLS1005
SPECTRA PREMIUM SP20A1H, SP20A2H
DELPHI HP10266
